500W
High Voltage Power Supply 500W for Electrostatic Oil Smoke Purifier
High Voltage Power Supply 500W for Electrostatic Oil Smoke Purifier, AC200-240V Input, DC9-16kV Output, Full Protection, CY-218
Specifications
- Input voltage
- AC220V ±10%
- Input current
- 3-5A
- Output voltage
- DC 9–16 kV
- Output current
- 45mA
- Power
- 500W
The CY-218 500W high voltage power supply is the high-power model of the CY series, developed for electrostatic oil smoke purification equipment. With a mature switching power supply design and intelligent constant voltage control, it delivers stable DC 9-16kV high voltage output at up to 45mA, maintains consistent purification efficiency under load and mains fluctuation, and integrates multi-layer protection for long-time continuous industrial operation — ideal for large electric fields and commercial/industrial ESP systems.
Parameter | Specification |
Model | CY-218 |
Series | CY Series High-Voltage Power Supply |
Rated Output Power | 500 W |
Output Voltage | DC 9–16 kV (adjustable) |
Output Current | 45mA |
Input Voltage | AC 220 V ±10% |
Input Frequency | 50 Hz |
Input Current | 3-5A |
Cooling | Built-in cooling fan, forced air |
Display | Built-in voltage & current display |
Terminals | 9-pin detachable terminal block |
Dimensions (L×W×H) | 240 × 130 × 82 mm |
Operating Temperature | -20 °C to +45 °C |
Applications | Commercial kitchen oil fume purifiers, industrial purifiers, integrated purifiers, smokeless grills |
